Shelly BLU Motion ZB

£19.99 Excl. VAT £16.66

In stock

Bluetooth & Zigbee motion sensor with integrated light sensor

The Shelly BLU Motion ZB is a compact, battery-powered motion and light sensor that helps your home respond automatically to movement. With Zigbee 3.0 and Bluetooth connectivity, it fits into a compatible smart home system to switch on lights, activate scenes and send notifications without wiring the sensor into the mains.

Its PIR sensor detects movement, while the built-in light sensor helps your automations respond to the brightness of the room. Adjust the motion sensitivity and configure the dark, twilight and bright thresholds so lights come on when they are needed. A compatible Bluetooth gateway or Zigbee hub is required for connected automations and app control.

• Zigbee 3.0 and Bluetooth 5 LE connectivity
• PIR motion detection with adjustable sensitivity
• Built-in light sensor with configurable brightness thresholds
• Up to 5 years of battery life from the included CR2477 battery
• BTHome support for compatible platforms
• Beacon mode with status updates every 30 seconds
• Configurable LED indication
• Simple adhesive mounting for indoor use

Lighting that responds to movement

Place the sensor in a hallway, entrance or other indoor space to trigger lighting when someone walks past. Combine motion detection with the light sensor so the same automation stays inactive when the room is already bright. Through your compatible gateway or smart home platform, you can also trigger scenes or receive notifications when movement is detected.

Bluetooth and Zigbee flexibility

Use Zigbee with a compatible Zigbee 3.0 hub, or Bluetooth with a BTHome-compatible system. For Shelly Smart Control, use a permanently powered Shelly Gen2 or newer WiFi and Bluetooth device as a Bluetooth gateway. Zigbee and Bluetooth can operate simultaneously, giving you flexibility as your smart home grows.

Fine-tune it for your room

Adjust motion sensitivity to suit the position of the sensor and configure the light thresholds between dark, twilight and bright. The optional LED gives visual feedback when movement is detected. Beacon mode provides regular status broadcasts for compatible integrations.

Small, wireless and easy to mount

The included CR2477 battery offers up to five years of operation, depending on use and settings. Attach the sensor to a clean, dry, smooth indoor surface using the supplied adhesive pad, with a clear view of the area you want to monitor. Keep it away from moisture, heat sources and direct sunlight.

  • Bluetooth operated

    Connect through a compatible Bluetooth gateway or BTHome platform.

  • Zigbee operated

    Integrate with a compatible Zigbee 3.0 hub; Zigbee and Bluetooth can operate simultaneously.

  • Integrated light sensor

    Configure dark, twilight and bright thresholds for lighting automations.

  • Long-lasting battery

    Up to 5 years of operation from the included CR2477 battery, depending on use.

  • Compact design

    A small wireless sensor with adhesive mounting for indoor spaces.

  • Smart scenes

    Use detected movement to trigger scenes, lighting and notifications through your compatible system.

Specification


Battery

  • Battery type 1 x 3V CR2477 (included)
  • Battery life Up to 5 years, depending on usage and settings

Features

  • Model SBMO-103Z
  • PIR motion sensor Yes, with adjustable sensitivity
  • Light sensor Yes; configurable dark, twilight and bright thresholds
  • Beacon mode Yes; status broadcasts every 30 seconds
  • LED indication Configurable
  • Encryption AES (CCM mode)
  • Mounting Adhesive mounting; indoors only
  • Colour White
  • Shell material Plastic
  • Ambient temperature -20°C to 40°C
  • Humidity 30% to 70% RH
  • CPU EFR32MG27
  • Flash 768kB

Connectivity

  • Bluetooth protocol 5 (LE)
  • Bluetooth RF band 2400 - 2483.5 MHz
  • Bluetooth maximum RF power < 8dBm
  • Bluetooth range Up to 10m indoors / 30m outdoors, depending on local conditions
  • Zigbee protocol Zigbee 3.0 / IEEE 802.15.4
  • Zigbee RF band 2405 - 2480 MHz
  • Zigbee maximum RF power < 8dBm
  • Zigbee range Up to 10m indoors / 30m outdoors, depending on local conditions
  • Simultaneous Zigbee and Bluetooth Yes
  • BTHome Supported
  • Gateway requirement Compatible Bluetooth gateway or Zigbee hub required for connected automations

Dimensions

  • Sensor (H x W x D) 28 x 37 x 37mm
  • Sensor with mount (H x W x D) 28 x 44 x 42mm
  • Sensor weight 28g
  • Sensor with mount weight 33g

How it works?

Remove the battery insulating tab and mount the sensor indoors with a clear view of the area.
Pair with a compatible Bluetooth gateway or Zigbee hub.
Configure sensitivity and light thresholds, then create and test your automations.
