Ogemray SW40

£32.99 Excl. VAT £27.49

In stock

WiFi-operated smart switch with power measurement, 1 channel, 25A

Introducing the Smart Relay Powered by Shelly, a cutting-edge device designed to provide precise control over large appliances with a capacity of up to 25A / 6000W. This innovative relay is equipped with advanced power measurement capabilities, allowing you to monitor and optimise energy usage in both residential and industrial settings.

Featuring the ShellyX chip, this product offers complete Shelly capabilities, ensuring seamless integration with leading smart home systems. With WiFi and Bluetooth connectivity, you can easily add it to your app and unlock all Shelly features without the need for a hub.

The smart relay is perfect for managing water heaters, industrial machines, and other large appliances, offering real-time energy consumption monitoring to help reduce costs. It supports smart schedules and scenes, allowing you to set custom routines based on your daily agenda or natural light cycles. The device includes overvoltage and overpower protection, ensuring safety and reliability. Its compact form factor, large terminals, and wall mounting anchors make it easy to install.

With support for scripting, webhooks, MQTT, and more, it offers high compatibility and easy control through the Shelly Smart Control app, with Alexa and Google Home integration coming soon. Additionally, it supports KNXnet / IP communication, making it a versatile choice for any smart home setup.

- WiFi and Bluetooth operated, no hub required
- Control up to 25A / 6000W
- Power metering for precise energy monitoring
- Smart schedules and scenes
- Overvoltage and overpower protection
- Compact form factor with large terminals
- Wall mounting anchors and bracket included
- Equipped with a Shelly chip for full capabilities
- Supports scripting, webhooks, MQTT, and more
- High compatibility with smart home systems
- Supports KNXnet / IP communication

  • Control up to 25A / 6000W

    Capable of managing most large home appliances or small industrial machines.

  • WiFi operated

    Connect the Ogenray SW40 to your Wi-Fi network. No HUB required.

  • Bluetooth

    Add devices quickly and easily to the Shelly Cloud app, using the Bluetooth connection.

  • Power metering with cloud data storage

    Ogemray SW40 provides precise monitoring of the power consumption.

  • Scripting

    Ogemray SW40 supports mjS scripting, allowing you to create custom features and functionalities.

Specification


Power

  • Power supply 110-240V ±10% 50/60Hz AC
  • Max switching voltage AC 240V
  • Max switching current AC 25A
  • Max switching power AC 6000W
  • Power consumption < 1.2W
  • Bluetooth Range (depending on local construction) • up to 30m/100ft outdoors
    • up to 10m/33ft indoors

Features

  • Clean contact relay No
  • Power measurement Yes
  • Voltage protection / Cutoff Yes
  • Current protection / Cutoff Yes
  • Max power protection / Cutoff Yes
  • Internal-temperature sensor Yes
  • Ambient temperature -20°C to 40°C / -5°F to 105°F
  • Humidity 30% to 70% RH
  • Schedules 20
  • Webhooks (URL actions) 20 with 5 URLs per hook
  • MQTT Yes
  • UDP Yes

Connectivity

  • Scripting Yes
  • WiFi Protocol 802.11 b/g/n (2.4 GHz)
  • WiFi RF band 2401-2486 MHz
  • WiFi max. RF power < 20dBm
  • Wi-Fi Range (depending on local construction) • up to 50m/160ft outdoors
    • up to 30m/100ft indoors
  • Bluetooth protocol 4.2
  • Bluetooth RF band 2400-2483.5 MHz
  • Bluetooth max. RF power < 4dBm

Dimensions

  • (H x W x L) 60x52.4x24mm / 2.36x2.06x0.94 in

How it works?

Download the Shelly Cloud application on your smartphone or tablet
Connect to your Wi-Fi router
Place the device wherever you wish
